Built in active power factor correction (PFC) technology, supporting a wide range of input voltages and enhancing power supply adaptability;
Adopting multi resonant soft switching technology to achieve high efficiency and high-density power output;
Output voltage ripple ≤ 400mV, comprehensive adjustment rate ± 0.5%;
Load 0-5KHz pulse current, output voltage fluctuation not exceeding ± 0.5%, ensuring stable output;
Integrated short-circuit protection, overcurrent protection, over temperature protection, etc., providing fault status and fault information reporting functions;
The output voltage can be automatically adjusted according to the voltage requirements of the pump source terminal (in conjunction with our company's dedicated drive module), improving the efficiency of constant current drive and simplifying the user debugging process;
Water cooling for heat dissipation.
Active PFC+multi resonant soft switching technology, with strong adaptability to wide voltage input, high conversion efficiency, high power density, and energy-saving.
Output voltage ripple ≤ 400mV, adjustment rate ± 0.5%, supports 5KHz pulse load fluctuation ≤ 0.5%, ensuring power supply stability.
Multiple protection mechanisms+fault self diagnosis, water cooling and heat dissipation+automatic voltage regulation, enhance system reliability and simplify operation and maintenance processes.
| Specifications | LSP3500-220A35 | LSP3500-220A70 | LSP6000-380A35 | LSP6000-380A70 | LSP8000-380A35 | LSP8000-380A70 |
|---|---|---|---|---|---|---|
| Input Voltage Scope | AC176V-264V，50/60Hz | AC320V-440V，50/60Hz three-phase | ||||
| Power Factor Compensation | APFC | |||||
| Output Voltage | 35V/70V | 35V/70V | 35V/70V | |||
| Output Current | 100A/50A | 171A/85.7A | 200A/114A | |||
| Output Voltage Quality | Voltage ripple: ≤ 400mV; steady-state voltage comprehensive adjustment rate: ± 0.5%; | |||||
| OutputPower | 3.5KW | 6KW | 8KW | |||
| Overall Efficiency | >91% | |||||
| Protection | Output overvoltage protection, short circuit protection, overcurrent protection, and over temperature protection | |||||
| Temperature | Temperature：-10-45℃；StorageTemperature：-20-65℃ | |||||
| Humidity |
Work：20-90%RH，No condensatio; nStorage：10-95%RH，No condensatio |
|||||
| Insulation | Voltage Resistant：1500Vac 10mA 60S，Insulation resistor≥ 10MΩ | |||||
| Safety regulations and electromagnetic compatibility | Complies with relevant industry standards | |||||
| Volume | 320×200×53mm | 379.5×200×50mm | ||||
| Weight | 2.5kg | 4kg | 4kg | |||
| Cooling Method | air cooling | water cooling | water cooling | |||
Warranty: 360 days
▶ The warranty period for power products is 12 months, calculated from the date of purchase.
▶ During the warranty period, faults that are not caused by human factors can be repaired free of charge; Malfunctions caused by human damage or excessive use require paid repairs.
▶ Before using this power supply, please read the manual carefully. We are not responsible for any damage or problems caused by improper use or failure to follow the manual
